A silver Hilux dual cab with a bull bar raising dust on a dirt flat at sunset

Performance · stages

Toyota 1KD⁠-⁠FTV 3L

Toyota Hilux N70 (KUN26) 2005–2015 · Toyota Prado 120 Series (KDJ120) 2003–2009 · Toyota Prado 150 Series (KDJ150) 2009–2015 · Toyota Fortuner 2005–2015

All dyno results

What this engine has actually gained

One chart per version of the engine, because the same code is not the same job. The years and the vehicle it went into change what it makes standard and what there is to find. Each chart is a single vehicle: a standard run the day it arrived, and the best run after the work, in 4th gear.

3.0L 1KD-FTV, Hilux N70

2005–2015

Measured on our dyno

Road speed in km/h

  • Tuned, measured
  • Standard

63 → 103 kW at the wheels

Measured on our dyno: power and torque against the standard run, 4th gear0255075100kW60708090100110Road speed (km/h) · 4th gear

Hover or tap the chart to read both curves at any speed.

The standard run and the tuned run are one vehicle, measured at the wheels on our own dyno, corrected to DD ATMC2 (factor 1.022), 29°C ambient, 2WD, both in 4th gear.

Best result
+39.4 kW+62.1%

This vehicle’s own before and after, whatever stage it ended up at. It is not a promise for a particular stage, and your 4WD is not this 4WD.

We have measured too few of these to publish a chart yet: 3.0L 1KD-FTV, Prado 150 Series; 3.0L 1KD-FTV, Prado 120 Series; 3.0L 1KD-FTV, Fortuner. Ask and we will tell you what we have seen on the bed.

The stages

Stage 1

adds service, intake clean, exhaust and tune

from $3,565.00parts, tune and servicing, everything in Stage 1

Get a fitted quote

Service, clean and breathe. We service the engine properly, chemically clean the intake and EGR, fit the exhaust, then write a map to the engine as it actually is on the day: fuel, timing and boost read off our own dyno rather than off a file somebody emailed us.

Most of what you feel is low down, between 1,500 and 2,500 rpm, which is where a loaded 4WD lives on a hill or in sand.

What this stage addsfrom $995.00 of parts

Exhaust

  • Big Boy Turbo‑Back to suit Hilux 3L 2005‑2015$995.00

The work in the price

  • Custom Dyno Tune, Stage 1 and 2$1,250.00
  • 4WD Minor Service$660.00
  • Intake and EGR chemical clean, single manifold$660.00
Stage 1, 3.0L 1KD-FTV, Hilux N70

Projected from our own dyno

Road speed in km/h

  • Tuned, projected
  • Standard

63 → 83 kW at the wheels

Projected from our own dyno: power and torque against the standard run, 4th gear0255075kW60708090100110Road speed (km/h) · 4th gear

Hover or tap the chart to read both curves at any speed.

The standard run below it is one 3.0L 1KD-FTV, Hilux N70, measured at the wheels on our own dyno, corrected to DD ATMC2 (factor 1.022), 29°C ambient, 2WD, in 4th gear.

The upper curve is 50% of what that same 4WD gained: the share a calibration carries before the exhaust and the intercooler go on. We dyno a vehicle as it arrives and again when the work is done, never once per stage, so this rung is worked out rather than measured.

Stage 2 Power

would add intercooler and intake, for power

Get a fitted quote

No intercooler, intake or transmission cooler is listed in this stage for the 1KD-FTV, so there is no Stage 2 Towing either. Ask us. There may be another way to get there.

The work in the price

  • Custom Dyno Tune, Stage 1 and 2$1,250.00
  • 4WD Minor Service$660.00
  • Intake and EGR chemical clean, single manifold$660.00

Stage 3

adds high-flow injectors and a bigger turbo

from $8,385.00parts, tune and servicing, everything in Stage 3Stage 1 + $4,820.00

Get a fitted quote

The point where the hardware sets the ceiling instead of the map. High-flow injectors put in more fuel than the factory ones can pass, and a larger turbo puts in enough air to burn it cleanly rather than making smoke.

This is a fitting job with a tune around it, not a bolt-on. It wants supporting work (cooling, clutch or converter, sometimes the fuel pump) and we will say so before anything comes apart.

What this stage adds$4,820.00 on top of Stage 1

  • The parts below+$4,380.00
  • Stage 3 tune in place of Stage 1's+$440.00

Injectors

  • Toyota Hilux 1KD‑FTV Injectors Service and High Flow (Exchange service)+60%$1,390.00

Turbo

  • Toyota Hilux KD‑G250 TitanG250$2,990.00

The work in the price

  • Custom Dyno Tune, Stage 3$1,690.00
  • 4WD Minor Service$660.00
  • Intake and EGR chemical clean, single manifold$660.00
Stage 3, 3.0L 1KD-FTV, Hilux N70

Projected from GTurbo's published figures

Road speed in km/h

  • Tuned, projected
  • Standard

63 → 180 kW at the wheels

Projected from GTurbo's published figures: power and torque against the standard run, 4th gear0255075100125150175kW60708090100110Road speed (km/h) · 4th gear

Hover or tap the chart to read both curves at any speed.

The standard run below it is one 3.0L 1KD-FTV, Hilux N70, measured at the wheels on our own dyno, corrected to DD ATMC2 (factor 1.022), 29°C ambient, 2WD, in 4th gear.

The upper curve is our own tuned run for this engine, drawn to GTurbo's published 180 kW at the wheels for this hardware with the rest of the stage on the 4WD.

GTurbo quote 650 Nm for the same build; torque here is shown on our dyno's scale.

Stage 4

adds a larger turbo in place of Stage 3's

from $9,645.00parts, tune and servicing, everything in Stage 4Stage 3 + $1,260.00

Get a fitted quote

A build, not a package. A larger turbo again, which is where the standard bottom end, the driveline and the cooling all start needing to be part of the conversation.

No curve for this rung: we have measured no Stage 4 on this engine and GTurbo publish no power figure for the hardware it takes. We will not draw one we cannot stand behind.

What this stage changes$1,260.00 on top of Stage 3

  • G300 turbo in place of Stage 3's G250+$500.00
  • Stage 4 tune in place of Stage 3's+$760.00

Turbo

  • Toyota Hilux KD‑G300 TitanG300$3,490.00

The work in the price

  • Custom Dyno Tune, Stage 4$2,450.00
  • 4WD Minor Service$660.00
  • Intake and EGR chemical clean, single manifold$660.00

Before you choose a stage

We will tell you what your build needs to stay road legal before any work starts.

GTurbo offer G250, G300, G320 for this engine, and injectors at +60%. A bigger step than the stages above is a conversation, not a checkout.
