Tier One Nissan GU Patrol Dual Cab Roof rack (LPLD)

$1,010.00

Includes $91.82 GST

SKU GUD-RR-LPLD

1
Get a fitted quote

Type your postcode for the delivery price.

The workshop confirms stock and freight before anything ships.

Bulky items like this one have delivery limits.

Not sure it fits your rig? Ask the workshop about this part.

Fits

  • Nissan Patrol GU1997 to 2016

01

Fitment

MakeModelYears
NissanPatrol GU1997 to 2016

02

Description

We’re excited to offer the Tier One GU Patrol Dual Cab Roof Rack Rail System: Rails, Rear Wing & Crossbars (Complete System)

GU Patrol Roof Rack Rail System: Rails & Crossbars (Complete System)

The Tier One Metalworks Roof Rack Rail System is the ultimate slimline mounting solution for the GU Patrol: Designed to be clean, strong and incredibly versatile. Proudly Australian-made and built for harsh touring conditions, this low-profile modular system delivers exceptional strength and durability without unnecessary bulk. With over 2 years of in-house development and real-world testing, these rails have been refined into one of the strongest slimline systems available.

Originally designed for direct-mounting rooftop tents, this platform now supports full touring setups with the addition of crossbars. The included crossbars create a complete roof-rack platform.

Manufactured from 3mm 304 Stainless Steel: a premium material choice selected for maximum corrosion resistance and long-term durability.

All items can still be purchased separately. For direct-mounting rooftop tents or existing platform racks head to Roof Rack Rail Sides


COMPLETE SYSTEM OVERVIEW

The complete GU Patrol system includes:

  • Left & Right Roof Rails
  • Four Crossbars (your choice of style)
  • All mounting brackets, hardware and rubber pinch weld needed
  • Overall Weight (Low profile light duty channel): 22.5kg
  • Overall Weight (High Profile Heavy Duty T Channel): 23kg
  • External Width: 1250mm
  • Rail Internal Width: 1130mm (front) / 1120mm (rear)
  • Overal length (including wing): 1535mm
  • Roof clearance: approx with Low-Profile Light-Duty Crossbars: 15mm
  • Roof clearance: approx with High-Profile Heavy-Duty Crossbars: 25mm
  • 304 stainless hardware (rail clamp bolts are powder coated satin black for a premium finish)
  • Powder coat Satin black

ROOF RAILS: DETAILS & SPECIFICATIONS

  • Suits GU Patrol Series 1-4
  • Clamps directly into factory gutters
  • 3mm 304 stainless steel: premium corrosion resistance & long-term durability
  • Passenger-side rail includes three awning mounting points and can be paired with our bolt-on awning brackets designed to bolt directly to the side rails.
  • Rail length: 1535mm
  • Weight: 9kg

CROSSBARS: OPTIONS & INFORMATION (SET OF 4 INCLUDED)

Low-Profile Light-Duty Cross Bars

  • 3mm Stainless Steel
  • Bottom edge is curved to follow the roofline
  • Roof clearance: 10–15mm
  • X4 Weight: 13.5kg

High-Profile Heavy-Duty Aluminum 80 × 25 mm Cross Bars

  • 80 × 25mm aluminum extrusion
  • Four-sided T-slots for modular mounting
  • Roof clearance: 25mm
  • X4 Weight: 14kg
  • Accepts M8 hardware
  • Designed as a heavy-duty mounting option with endless mounting locations

DIRECT TENT MOUNTING (IMPORTANT)

This complete system includes four crossbars, however For the lowest possible tent height, you can mount your rooftop tent directly to the rails. To do this, purchase the Roof Rack Rail Sides separately.


WHY IS STAINLESS MORE EXPENSIVE?

Stainless steel costs significantly more than mild steel in both raw material and manufacturing time. We’ve chosen 304 stainless because it delivers superior corrosion resistance, long-term durability and a premium finish: making it the best option for serious touring and harsh Australian environments.


FITTING INFORMATION

If you’re unsure about fitment or your setup, contact us anytime: we’re always happy to help you get it right the first time.


DISCLAIMER

Tier One Metalworks is not liable for any damage or injury caused by improper use or installation.
Always adhere to the vehicle manufacturer's load ratings and installation guidelines.

Freight & fitting services

Since the product ships from Melbourne, please be aware that store pick-ups in Brisbane will incur a freight fee.

Legendex offers professional fitting at our head office. Contact our team to discuss fitted pricing and ensure your product is installed correctly and to the highest standard.

03

Specifications

BrandTier One Metalworks
SKUGUD-RR-LPLD
Weight26.1 kg
CategoriesRoof racks
